Navdha evaporative coolers are available with two types i.e. Single Skin and Double Skin. The corner sheet metal is of cast iron with no insulation while double skin has PVC with Puff insulation that's CFC free.

Working Phenomenon

Fresh Ambient Air shall be sucked- in through fresh air high efficiency dry panel type filters and the air so taken in shall come in contact with water when it looses its heat and the latent heat of vaporization needed for the water to evaporate is taken from the sensible heat of air. Water then evaporates cooling the air in the process. It is within the cooling media where the process of heat and mass transfer takes place. Since no heat is added or removed from the system, it is therefore, called an adiabatic saturation process and works on the principle of "Cooling is caused by evaporation". The saturation efficiency of air after passing through the water wash section comes to around 80-90%.

Salient Features of Marco Evaporative cooling unit

• Fill type system can attain saturation efficiencies of 90% as against 60% efficiency of conventional system.
• Compact pre-fabricated design to take less space, volume nearly 40% of comparable machine.
• No masonary work required for room and can be located inside or outside a building.
• Power consumption nearly 50% of any comparable spray machine due to low pump power and low pressure drop.
• Maintenance negligible as no nozzles are involved and hence trouble free service.
• Low noise level in machines as there are no high pressure nozzles.
• Quick installation as machine is factory fabricated and has flexibility to re-locate at any time.
